1. The imported linear guide way ensures the high precision and the long service.
2. The stepper motor guarantees cutting and engraving smooth.
3. The structure is strong enough to ensure the moving stable.
4. High quality laser tube provides the strong beam and long service life.
5. Focus lens and reflect molybdenum mirrors guarantee the powerful cutting strength.
6. The anti-pollution design improves the stability of the whole machine greatly.
7. Configure higher power laser tube.
High precision Taiwan Hiwin double guide rail, 3-phase stepper motor and driver, belt transmission, channel-type feeding, up&down worktable, honey-comb or aluminum strip worktable, circulation water cooling, hydraulic protection, dust and smoke exhausting, huff protection, etc.
This machine is widely applied in the field of advertising industry, decoration, furniture, model manufacturing, and handcraft industry for the fine engraving, cutting and hollowing out on almost all non- metallic materials with all kinds of characters, graphs, images, trademarks and so on.
|Engraving Area (mm)W*L||500*300||900*600||1300*900||1600*1000||1300*2500|
|Laser tube power||40W 60W 75W 90W 100W 130W 150W 260w|
|Laser Type||CO2 sealed laser tube RECI brand|
|Resetting positioning accuracy||≤±0.01mm|
|Laser Output||1-100%software setting|
|Cooling mode||Circulating-water-cooling and protection system|
|Machine control and drive||Speedy DSP controlling, stepper motor|
|Cutting Platform||knife-strip platform|
|Min. shaping character||Character 2.0mm×2.0mm,English1.0mm×1.0mm|
|Power Supply||AC220V 50HZ|
|Operating system||DSP off-line control system|
|Dictate format||*.plt,*.dst,*.dxf,*.bmp,*.dwg,*.al,*las etc.|
|Operating Humidity||5-95%(Free of Condensed Water)|
|Compatible Software||CorelDraw ,AutoCAD transmit directly|
|Optional Spare Parts||Rotary system, Industrial Chiller, Infrared Locating System,Laser Tube, Up-down table|
|Consumable Spare Parts||Laser Tube and laser lens|
|Other machine size||600*400mm,1300*1000mm,1200*1200mm,|
1600*3000mm,1800*1000mm and other customized
|Laser type||CO2 laser tube,RECI brand (Yongli and Weiju can option)|
|Power supply||110V / 220V/ 50-60HZ|
|Min. shaping character||English 1 x 1 mm|
|Graphic format supported||BMP, PLT, DST, DXF, AI|
|Software supported||CorelDraw, PhotoShop,AutoCAD,TAJIMA|
|Location precision:||less than 0.02mm|
|Applicable material||Acrylic, crystal, MDF, ceramic, leather, cloth, fabric,glass,stone,wood etc.|
Applicable Material (metal and Nonmetal)
Acrylic, Plastic, Plank, ABS, Wood, Plywood, Bamboo, Paper, Organic glass, MDF, PVC, Rubber, Density board, Cloth, Leather, Derma, Corfam, Textile, Chemical leather, metal ,SS,etc.
Engraving and Cutting Nometal Materials(Only for reference)
|Laser tube Power||50w||60w||80w||100w||130w||150w||280w|
1.12 months guarantee of the whole machine
2.Main parts(excluding the consumables)shall be changed free of charge if there is any problem during the warranty period.
3.Lifetime maintenance free of charge
4.We will provide the consumable parts at an agency price when you need replacement
5.Machine has been adjusted and tested before delivery
6.Our staff can be sent to your company to install or adjust if necessary
T/T 30% payment for deposit, after the machine finished, we will take the testing videos for you to check the machine, after you satisfied the machine you pay the left 70% payment. Then we will delivery the machine.
1. 24hours Technical support by Email or Calling.
2. English manual and CD video for machine using and maintaining.
3. Hardware: 1 years for machine (without person damaged).
Software: Whole life on update for free.
Maintenance and technological support: Whole life
Packaging and delivery:
|Delivery||Within 7 working days for production, we will arrange delivery after received the total payment|
|Packing||Firstly, Packed the machine with plastic sheet for clearing and damp proofing.|
Secondly, Then put the machine in the plywood case for safety and clashing.
Thirdly, Transport the plywood case into the container.
We are located in jinan City of China, a manufacturer of cnc router, cnc laser and plasma cutting machines.
STARMAcnc has over 58 employees and a factory with more than 10000 square meters. We has our own design and development department.At the same time created "STARMAcnc" brand.
Each product is strictly examined according to ISO9001 (QCS) and ISO14001 (EMS) standards before it is sent out of our factory. And up to CE &FDA &SGS certificate and win Alibaba good faith enterprise.STARMA persist on the mission of "supplying our customers with the best CNC&Laser equipments and solutions".
In us, TOP QUALITY&FIRST-RATE SERVICE IS OUR SOUL AND CULTURE! BELIEVE US AND CHOOSE US, YOU ARE RIGHT!
Question 1:How long about the machine's guarantee ?
Answer :1 year
Question 2:How about your after service ?
Answer :Technical support by phone, e-mail or whatsapp, wechat around the clock.
Question 3: How can we install the machine?
Answer :Friendly English version manual and operation video CD disk.
Question 4: How about the payment terms?
Answer:30% T/T for deposit, 70%T/T paid before shipping.
T/T, West Union, Paypal
Question 5: Do You Arrange Shipment For The Machines?
Answer: Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.
Jinan Starma Machinery Equipment Co.,Ltd.
